Advantages:
- Independent plate heating muffle
- Stainless steel outer casing
- Pantograph opening door
- Versatile and intuitive programming
- Multi-language software
Designed with the criteria acquired in over 70 years of experience, Manfredi pre-heating furnaces for cylinders feature the most up-to-date and reliable programming systems, while maintaining extreme ease of use. The chamber (available in two different sizes) consists of 4 independent plates for greater resistance to thermal shock. Their profile increases the radiating surface for greater thermal efficiency, ensures uniform temperature distribution and effective evacuation of waxes still in the liquid phase, preventing them from remaining inside the cylinder. The exterior of the chamber, made entirely of stainless steel, is corrosion-free and therefore practically indestructible. The door, fitted with a highly insulating refractory material, prevents heat loss to the outside. In addition, the effective parallelogram opening system protects the operator from accidental contact with hot surfaces and guarantees easy opening over time thanks to the self-lubricating materials with which it is constructed. The oven has 10 storable programmes, each with 3 different stations. Ventilation control is available for each station.
* N: Natural ventilation
